一 、docker 部署 mind-map 思维导图

原项目仓库地址：https://github.com/wanglin2/mind-map

1 、创建 docker-compose.yml

1
2
3
4
5
6
7
8
9
10
11
12
13
14
mkdir -p /vol1/1000/compose/mind-map && \
cd /vol1/1000/compose/mind-map && \
touch docker-compose.yml && \
cat > docker-compose.yml <<'EOF'
services:
  mind-map:
    image: shuiche/mind-map
    restart: unless-stopped
    container_name: mind-map
    ports:
      - 8256:8080
EOF

docker-compose up -d

2 、拉取并运行

1
2
cd /vol1/1000/compose/mind-map && \
docker-compose up -d

3 、停止并删除

1
2
cd /vol1/1000/compose/mind-map && \
docker-compose down

4 、拉取镜像

1
2
cd /vol1/1000/compose/mind-map && \
docker-compose pull

5 、容器升级

1
2
3
4
5
cd /vol1/1000/compose/mind-map && \
docker-compose down && \
docker-compose pull && \
docker-compose up -d && \
docker image prune -f

6 、查看容器日志

1
docker logs mind-map

二 、容器维护命令

1 、查看所有运行容器的名称

1
docker ps -a --format "{{.Names}}"

2 、停止 mind-map 容器

1
docker stop mind-map

3 、启动 mind-map 容器

1
docker start mind-map

4 、重启 mind-map 容器

1
docker restart mind-map

5 、进入 mind-map 容器

1
2
3
## Ctrl+D 退出容器
## docker exec -it mind-map sh
docker exec -it mind-map bash

6 、查看 mind-map 配置文件

1
cat /vol1/1000/compose/mind-map/docker-compose.yml

Nginx 配置

后台地址：https://mind-map.example.com:666

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
mkdir -pm 755 /etc/nginx/conf.d && \
touch /etc/nginx/conf.d/dufs.conf && \
cat <<'EOF' | sed '1!{/^[[:space:]]*#/d;/^[[:space:]]*$/d}' > /etc/nginx/conf.d/dufs.conf
## nginx 反向代理: mind-map 思维导图
server {
    listen 666 ssl;
    listen [::]:666 ssl;
    server_name mind-map.example.com;
    ssl_certificate /etc/nginx/keyfile/cert.pem;
    ssl_certificate_key /etc/nginx/keyfile/key.pem;
    ssl_protocols TLSv1 TLSv1.1 TLSv1.2 TLSv1.3;
    ssl_prefer_server_ciphers on;
    ssl_ciphers HIGH:!aNULL:!MD5;
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Content-Type-Options nosniff always;
    add_header X-Frame-Options "SAMEORIGIN" always;
    sendfile on;
    tcp_nopush on;
    client_max_body_size 10G;
    error_page 404 500 502 503 504 /50x.html;
    location = /50x.html {
        root /var/www/html;
    }
    location / {
        proxy_pass http://10.10.10.251:8256;
        proxy_set_header Host $http_host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header Range $http_range;
        proxy_set_header If-Range $http_if_range;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_http_version 1.1;
        proxy_read_timeout 300s;
        proxy_connect_timeout 300s;
        proxy_buffering on;
        proxy_buffer_size 4k;
        proxy_buffers 8 16k;
        proxy_busy_buffers_size 24k;
        proxy_max_temp_file_size 0;
    }
}
EOF

sudo systemctl restart nginx
